Hybrid Battery Backup Dynamic UPS
Uninterruptible Power Supplies › Dynamic Power Supplies › All
Description
• Natural sine wave signal generated without using semiconductor materials
• Wide input voltage tolerance of -50% and +15%
• ±5% input frequency tolerance
• Efficiency up to 96%
• 99% harmonic suppression under all conditions
• Input current harmonic distortion below 3%
• Unlimited crest factor
• High short-circuit withstand capability (14xIn)
• Input power factor 0.99
• Ability to operate for 1 hour at 110% load and 2 minutes at 150% load
• 100% galvanic isolation
• 650,000 hours MTBF
• 25-year operating lifetime
• Low maintenance costs
• Low operating costs
• 40% lower battery usage
• Natural ventilation
• Full output capacity even at capacitive power factor
• Compatible with BMS and many communication systems
• Container cabinet solution option
• Water-cooled solution option
• The most important feature of dynamic uninterruptible power supplies, which are a continuous and clean energy source, is their unique synchronous machine that generates a natural sine wave independently from the grid. UNIBLOCK-R is a model with battery backup structure and internal redundancy. This product provides solutions for medium and low voltage conditions and is manufactured as a single unit between 150kVA-1100kVA without parallel connection.
• The UNIBLOCK-R dynamic hybrid UPS provides redundancy through 4 independent internal lines, helping to meet Tier 3 and Tier 4 requirements. Your critical loads achieve high reliability. When choosing the UBR Dynamic UPS, the need for compensation panels and air conditioning systems is eliminated. A much more efficient, high-quality, safe, and long-lasting solution is achieved with a single system.
• Under dynamic load conditions, even during sudden peak currents, the voltage newly generated by the grid-independent synchronous motor provides a clean and natural sine wave without interference at the UPS output.
• Short-circuit currents occurring on the load side are eliminated up to 14 times the nominal current, ensuring the continuation of selective critical load operation.
• Thanks to independent grounding, an additional isolation transformer is not required.
• Since harmonic filters and capacitors are not required, high efficiency is achieved in a smaller footprint.
• UNIBLOCK-R dynamic hybrid UPS systems have high earthquake resistance standards. They are designed to withstand earthquake accelerations of 1G horizontally and 0.5G vertically.
• Since battery operation is used only during power outages and the AC ripple level is much lower, battery lifetime is extended by 40%.
• Natural system ventilation is provided through the industrial fan integrated into the UNIBLOCK synchronous machine. No additional air conditioning system is required.
• Wide input voltage tolerance of -50% and +15%
• ±5% input frequency tolerance
• Efficiency up to 96%
• 99% harmonic suppression under all conditions
• Input current harmonic distortion below 3%
• Unlimited crest factor
• High short-circuit withstand capability (14xIn)
• Input power factor 0.99
• Ability to operate for 1 hour at 110% load and 2 minutes at 150% load
• 100% galvanic isolation
• 650,000 hours MTBF
• 25-year operating lifetime
• Low maintenance costs
• Low operating costs
• 40% lower battery usage
• Natural ventilation
• Full output capacity even at capacitive power factor
• Compatible with BMS and many communication systems
• Container cabinet solution option
• Water-cooled solution option
• The most important feature of dynamic uninterruptible power supplies, which are a continuous and clean energy source, is their unique synchronous machine that generates a natural sine wave independently from the grid. UNIBLOCK-R is a model with battery backup structure and internal redundancy. This product provides solutions for medium and low voltage conditions and is manufactured as a single unit between 150kVA-1100kVA without parallel connection.
• The UNIBLOCK-R dynamic hybrid UPS provides redundancy through 4 independent internal lines, helping to meet Tier 3 and Tier 4 requirements. Your critical loads achieve high reliability. When choosing the UBR Dynamic UPS, the need for compensation panels and air conditioning systems is eliminated. A much more efficient, high-quality, safe, and long-lasting solution is achieved with a single system.
• Under dynamic load conditions, even during sudden peak currents, the voltage newly generated by the grid-independent synchronous motor provides a clean and natural sine wave without interference at the UPS output.
• Short-circuit currents occurring on the load side are eliminated up to 14 times the nominal current, ensuring the continuation of selective critical load operation.
• Thanks to independent grounding, an additional isolation transformer is not required.
• Since harmonic filters and capacitors are not required, high efficiency is achieved in a smaller footprint.
• UNIBLOCK-R dynamic hybrid UPS systems have high earthquake resistance standards. They are designed to withstand earthquake accelerations of 1G horizontally and 0.5G vertically.
• Since battery operation is used only during power outages and the AC ripple level is much lower, battery lifetime is extended by 40%.
• Natural system ventilation is provided through the industrial fan integrated into the UNIBLOCK synchronous machine. No additional air conditioning system is required.
