Diesel-Supported Dynamic UPS
Uninterruptible Power Supplies › Dynamic Power Supplies › All
Description
• Natural sine wave generated without the use of semiconductor materials
• Wide input voltage tolerance: -50% / +15%
• ±5% input frequency tolerance
• Efficiency up to 96%
• 99% harmonic suppression under all operating conditions
• Input current harmonic distortion below 3%
• Unlimited crest factor
• High short-circuit withstand capability (14×In)
• Input power factor: 0.99
• Capable of operating for 1 hour at 110% load and 2 minutes at 150% load
• 100% galvanic isolation
• MTBF of 1,850,000 hours
• 25-year service life
• Low maintenance costs
• Low operating costs
• 40% lower battery usage
• Natural ventilation
• Full output power capability even with capacitive power factor loads
• Compatible with BMS and various communication systems
• Containerized enclosure solution available
• The most important feature of dynamic uninterruptible power supplies that provide continuous and clean energy is their unique synchronous machine, which generates a natural sine wave independently of the utility grid.
• The UNIBLOCK-TD+ is a diesel-engine-driven continuous power system available with either battery backup or kinetic energy storage options.
• It is a compact uninterrupted power infrastructure that does not require auxiliary systems such as an external generator set, power factor correction system, distribution panel, or synchronization unit.
• Suitable for both Medium Voltage (MV) and Low Voltage (LV) applications, the UNIBLOCK-TD+ is available as a standalone system without parallel operation in capacities of 625kVA–3000kVA for the UBTD+ with PowerBridge model and 625kVA–1670kVA for the UBTD+ with Battery model.
• The UNIBLOCK-TD+ also provides scalable solutions up to 50MVA through parallel operation.
• Depending on customer requirements, the system can be equipped with various high-quality diesel engine options.
• By selecting the dual-output option, a single system can function as both a UPS and a standby generator.
• A single integrated system delivers a significantly more efficient, higher-quality, safer, and longer-lasting power solution.
• Thanks to the three-leg reactor called MAGIC CHOKE, current harmonics flowing from the load to the utility are suppressed, voltage harmonics from the utility to the load are isolated, and utility-fed short-circuit currents are limited, providing complete electrical decoupling.
• By selecting the POWERBRIDGE kinetic energy storage system, high-efficiency uninterrupted power is provided without the need for battery banks.
• Available in 16.5MJ, 2×16.5MJ, 21MJ, 2×21MJ, 35MJ, 2×35MJ, 60MJ, and 80MJ configurations, the system provides backup during short power interruptions by converting kinetic energy into electrical energy.
• The kinetic energy storage system offers a unique capability by providing more than one minute of backup time at full load during power outages.
• During diesel operation, the uniquely designed bidirectional POWERBRIDGE kinetic energy storage system ensures outstanding frequency stabilization while supplying dynamic loads without interruption.
• Even under dynamic load conditions and sudden peak currents, the UNIBLOCK-TD+, with its unlimited crest factor capability and 100% load-step performance, regenerates voltage in its grid-independent synchronous machine to deliver a clean, interference-free, natural sine wave at the UPS output.
• Short-circuit currents occurring on the load side are limited up to 14 times the rated current, ensuring uninterrupted operation of selective critical loads.
• Thanks to the industrial fan integrated into the UNIBLOCK synchronous machine, natural system ventilation is provided, eliminating the need for an additional air-conditioning system.
• Wide input voltage tolerance: -50% / +15%
• ±5% input frequency tolerance
• Efficiency up to 96%
• 99% harmonic suppression under all operating conditions
• Input current harmonic distortion below 3%
• Unlimited crest factor
• High short-circuit withstand capability (14×In)
• Input power factor: 0.99
• Capable of operating for 1 hour at 110% load and 2 minutes at 150% load
• 100% galvanic isolation
• MTBF of 1,850,000 hours
• 25-year service life
• Low maintenance costs
• Low operating costs
• 40% lower battery usage
• Natural ventilation
• Full output power capability even with capacitive power factor loads
• Compatible with BMS and various communication systems
• Containerized enclosure solution available
• The most important feature of dynamic uninterruptible power supplies that provide continuous and clean energy is their unique synchronous machine, which generates a natural sine wave independently of the utility grid.
• The UNIBLOCK-TD+ is a diesel-engine-driven continuous power system available with either battery backup or kinetic energy storage options.
• It is a compact uninterrupted power infrastructure that does not require auxiliary systems such as an external generator set, power factor correction system, distribution panel, or synchronization unit.
• Suitable for both Medium Voltage (MV) and Low Voltage (LV) applications, the UNIBLOCK-TD+ is available as a standalone system without parallel operation in capacities of 625kVA–3000kVA for the UBTD+ with PowerBridge model and 625kVA–1670kVA for the UBTD+ with Battery model.
• The UNIBLOCK-TD+ also provides scalable solutions up to 50MVA through parallel operation.
• Depending on customer requirements, the system can be equipped with various high-quality diesel engine options.
• By selecting the dual-output option, a single system can function as both a UPS and a standby generator.
• A single integrated system delivers a significantly more efficient, higher-quality, safer, and longer-lasting power solution.
• Thanks to the three-leg reactor called MAGIC CHOKE, current harmonics flowing from the load to the utility are suppressed, voltage harmonics from the utility to the load are isolated, and utility-fed short-circuit currents are limited, providing complete electrical decoupling.
• By selecting the POWERBRIDGE kinetic energy storage system, high-efficiency uninterrupted power is provided without the need for battery banks.
• Available in 16.5MJ, 2×16.5MJ, 21MJ, 2×21MJ, 35MJ, 2×35MJ, 60MJ, and 80MJ configurations, the system provides backup during short power interruptions by converting kinetic energy into electrical energy.
• The kinetic energy storage system offers a unique capability by providing more than one minute of backup time at full load during power outages.
• During diesel operation, the uniquely designed bidirectional POWERBRIDGE kinetic energy storage system ensures outstanding frequency stabilization while supplying dynamic loads without interruption.
• Even under dynamic load conditions and sudden peak currents, the UNIBLOCK-TD+, with its unlimited crest factor capability and 100% load-step performance, regenerates voltage in its grid-independent synchronous machine to deliver a clean, interference-free, natural sine wave at the UPS output.
• Short-circuit currents occurring on the load side are limited up to 14 times the rated current, ensuring uninterrupted operation of selective critical loads.
• Thanks to the industrial fan integrated into the UNIBLOCK synchronous machine, natural system ventilation is provided, eliminating the need for an additional air-conditioning system.
