PILLER Dynamic UPS with Kinetic Energy Storage (UBT+ with PowerBridge)

• Natural sine wave signal generated without using semiconductor materials
• Wide input voltage tolerance: -50% / +15%
• ±5% input frequency tolerance
• Efficiency up to 97%
• 99% harmonic suppression under all operating conditions
• Input current harmonic distortion below 3%
• Unlimited crest factor
• High short-circuit withstand capability (14×In)
• Input power factor: 0.99
• Operation capability for 1 hour at 110% load and 2 minutes at 150% load
• 100% galvanic isolation
• Extremely long MTBF period
• 25-year service life
• Low maintenance costs
• Low operating costs
• 40% lower battery usage
• Natural ventilation
• Full-capacity output capability even with capacitive power factor loads
• Compatible with BMS and various communication systems
• Container cabinet solution option
• Water-cooled solution option
• The most important feature of dynamic uninterruptible power supplies providing continuous and clean energy is their unique synchronous machine that generates a natural sine wave independently from the utility grid.
• UNIBLOCK-T+ with PowerBridge is a model equipped with Kinetic Energy Storage technology.
• This product, suitable for Medium Voltage (MV) and Low Voltage (LV) applications, is manufactured as a single unit between 625 kVA and 2500 kVA without parallel operation.
• When choosing a Dynamic UPS with Kinetic Energy Storage, the need for additional equipment such as power factor correction panels and air-conditioning systems is eliminated.
• A single system provides a much more efficient, high-quality, safe, and long-lasting solution.

• Thanks to the three-leg reactor called MAGIC CHOKE, current harmonics from the load to the grid are suppressed, voltage harmonics from the grid to the load are isolated, and grid-driven short-circuit currents are limited, providing electrical decoupling.
• With the selection of the POWERBRIDGE kinetic energy storage system, high-efficiency uninterrupted energy is provided without using battery banks.
• With 16.5MJ, 2×16.5MJ, 21MJ, 2×21MJ, 35MJ, 2×35MJ, 60MJ, and 80MJ options, backup power is provided during short interruptions by converting kinetic energy into electrical energy.
• The kinetic energy storage system provides a unique feature with more than 1 minute of backup time at full load during power outages.
• Under dynamic load conditions and sudden peak currents, the voltage regenerated by the grid-independent synchronous motor provides a clean and natural sine wave without interference at the UPS output.
• Short-circuit currents occurring on the load side are eliminated up to 14 times the rated current, ensuring continued selective operation of critical loads.
• Since battery operation is used only during power interruptions and the AC ripple level is significantly lower, battery life is extended by 40%.
• Thanks to the industrial fan integrated into the UNIBLOCK synchronous machine, natural system ventilation is achieved and no additional air-conditioning system is required.
• In cogeneration plants, it eliminates energy fluctuations and provides uninterrupted and stable power.
