Battery-Backed Dynamic UPS
Uninterruptible Power Supplies › Dynamic Power Supplies › All
Description
• Natural sine wave output generated without the use of semiconductor materials
• Wide input voltage tolerance: -50% / +15%
• ±5% input frequency tolerance
• Efficiency up to 97%
• 99% harmonic suppression under all operating conditions
• Input current harmonic distortion below 3%
• Unlimited crest factor
• High short-circuit withstand capability (14 × In)
• Input power factor: 0.99
• Operates for 1 hour at 110% load and 2 minutes at 150% load
• 100% galvanic isolation
• MTBF of 850,000 hours
• 25-year service life
• Low maintenance costs
• Low operating costs
• 40% lower battery usage
• Natural ventilation
• Full power output even with capacitive power factor loads
• Compatible with BMS and various communication systems
• Containerized cabinet solution available
• Water-cooled solution available
• The most important feature of dynamic uninterruptible power supplies providing continuous and clean energy is their unique synchronous machine, which generates a natural sine wave independently of the utility grid.
• UNIBLOCK-T+ with Battery is the battery-backed model of the system.
• Designed for both Medium Voltage (MV) and Low Voltage (LV) applications, it is available as a standalone unit with capacities ranging from 625 kVA to 1670 kVA without requiring parallel operation.
• When choosing a battery-backed Dynamic UPS, there is no need for additional equipment such as power factor correction panels or air-conditioning systems.
• A single integrated system delivers a more efficient, higher-quality, safer, and longer-lasting power solution.
• The three-leg reactor known as MAGIC CHOKE suppresses current harmonics flowing from the load to the grid, isolates voltage harmonics coming from the grid to the load, and limits grid-fed short-circuit currents, providing complete electrical decoupling.
• Even under dynamic load conditions and sudden peak currents, the voltage regenerated by the grid-independent synchronous machine provides a clean, interference-free, natural sine wave at the UPS output.
• Short-circuit currents on the load side are limited up to 14 times the rated current, ensuring continuous operation of selective critical loads.
• Since the batteries operate only during power outages and are subjected to significantly lower AC ripple, battery service life is extended by up to 40%.
• The industrial fan integrated into the UNIBLOCK synchronous machine provides natural system ventilation, eliminating the need for an additional air-conditioning system.
